6 Zone Mixer Amplifier with USB/SD/FM/Bluetooth DC-120ZB/DC-240ZB/DC-350ZB/DC-500ZB

In Stock

6 Zone Mixer Amplifier with USB/SD/FM/Bluetooth DC-120ZB/DC-240ZB/DC-350ZB/DC-500ZB，Rate power output at 120W, 240W, 350W to 500W，Speaker output of 100V & 4 Ohm-16 Ohm

Features:

Compact 1U size public address amplifier
Tabletop mixer amplifier with Mp3 player, FM radio & blue tooth
Rate power output at 120W, 240W, 350W to 500W
Support 6 zone outputs,each zone has a separate key and level indication
Speaker output of 100V & 4 Ohm-16 Ohm
Mp3 player with USB/SD input on front panel, IR remote control for Mp3 player, FM radio and Bluetooth
LED indicators for signal, po w e r , c l i p a n d protect
Dip off, Priority MUTE>EMC>MIC1>MIC2, MIC 3>Others
Dip 1 on, Priority MUTE>EMC>MIC1, MIC2, MIC 3>Others
Mic1-3 switchable inputs unbalanced 6.3mm jack
Aux 1-2 input of RCA input and one EMC in and one output by RCA
Volume control for Mic1-3, Aux1-2, bass/treble and master
Complete amplifier protection includes short-circuit, clip, overload and high temp
AC110V-230V switchable power supply system and 24V DC in

Specification:

Model	DC-120ZB	DC-240ZB	DC-350ZB	DC-500ZB
Description	6 Zone Mixer Amplifier with USB/SD/FM/Blue Tooth
Rated Power Output	120W	240W	350W	500W
Speaker Outputs	100V & 4 -16 Ohm
Connector	MIC switchable input 1-3 balanced phoenix terminal MIC 1 with phantom power,switch controlled by Dip 2 AUX 1-2 inputs by RCA; EMC in and 1 output by RCA
Priority	Dip off, Priority MUTE>EMC>MIC1>MIC2, MIC 3>Others; Dip 1 on, Priority MUTE>EMC>MIC1,MIC2,MIC 3>Others;
Input	Mic1-3: 25mV±5%, AXU1-2:200mv±5%; EMC:421mv±5%
Input level, impedance	AUX：10KΩ /MIC：1KΩ
Frequency Response	50 Hz-20 kHz
S/N Ratio	>85dB
THD	＜ 0.1%
Protection	Short-circuit, clip, overload and high temp protection
Power Consumption	200W	400W	500W	650W
Power Supply	AC110-230V; 50-60Hz, DC 24V
Dimension	484 × 370 × 45 mm
Weight	5.1kg	5.1kg	5.2kg	5.2kg
