DST-4120 Stereo Power Amplifier with DSP is one two channel low impedance amplifier built-in DST processor Network audio, ideal for IP network multiple audio streaming professional sound system, 4 channel professional audio power amplifier, 4 channel input output, 4 IN 4 OUT DST processor, support 100V & 8 Ohm speaker connection.
Description The DST-4500 is 4-channel flexible amplifiers with DSP processor for high performance installation sound system. The 4-channel power amplifiers with DSP processor are rated power output at 4 x 120W to 4 x 500W@ 8 Ohm which provide an enormous flexibility for different size sound system applications. The DSP processor in combination with remote management software gives user friendly experience with intuitive functions overview for easy configuration. Acoustics can be optimized using noise gate, matrix mixer, PEQ, crossover, delay, compressor, Butterworth, Bessel, Linkwitz6~24. These settings can be custom configured using the English remote software by mini USB port on front panel. Loudspeaker protection is provided by an output power limiter whereby the maximum output power for every channel (in Watt) can be configured. Configuration is made simple with loudspeaker presets and full system configurations which can be selected from a library and uploaded to the amplifier. This ensures the best acoustical performance with a bullet-proof loudspeaker protection. The amplifier built-in 4 Input 4 Outputs high performance DSP processor, which can ensure each input and output could be managed respectively. One mini USB on front panel for DSP configure.The amplifiers support 100V & 8 Ohm both commercial audio & professional audio applications, where an output selector could enable this function for dedicated sound system. The installation of this 4-channel amplifier with DSP allows receiving and sending of low latency, high quality audio with multiple Presets. Feature: • 4-channel amplifier with DSP processor • Rated power output at 4 x 120W to 4 x 500W@ 8 Ohm • Support 8Ω & 100V, mono, free matrix, stereo modes • Built-in DSP with EQ, gain control, crossover, delay, limiter, high-pass filter & low-cut filter • 31 bands of input PEQ and 10 bands of output PEQ • 30 presets of DSP (Digital Signal Processor) • 4 In 4 Out matrix DSP processor • One mini USB port on front panel for DSP configure • Four channel speaker outputs 8 Ohm & 100V • Four balanced line inputs by phoenix connector • Each input with separate gain control. • Each four channel with high-cut filter. • 1U height 19” rack mount type power amplifier • Complete short circuit, overload, high temp, clip and DC protection Specification:
| Model | DST-4500 | DST-4350 | DST-4240 | DST-4120 |
| Description | Class-D Four Channel Power Amplifier | |||
| Rated Power Output | 4 x 500W | 4 x 350W | 4 x 240W | 4x120W |
| Speaker Output | 100V and 8Ω,mono, free matrix, stereo, | |||
| DSP | EQ, gain control, crossover, delay, limiter, high-pass filter & low-cut filter, Butterworth, Bessel, Linkwitz6~24 Mini USB for configure, monitoring & control via fully manageable remote PC software | |||
| Frequency Response | L/H Cut OFF 20Hz-20KHz (+1/-2dB) L/H Cut ON 70Hz-10KHz (+1/-3dB) | |||
| Input | 0.775V, 0dBu, balanced phoenix connector by four channels | |||
| THD | <0.1% (1KHz/-3dBv, 100W) | |||
| S/N Ratio | ＞80dB | |||
| Protection | DSP limiter, High temperature, DC, high frequency, short circuit, back EMF, peak current limiter, Back EMF, Surge current limiter, startup delay, power circuit breaker protection, power over voltage , under voltage protection | |||
| Power Consumption | 2100W | 1650W | 1100W | 650W |
| Power Supply | 230V AC & 24V DC, 50-60Hz | |||
| Dimension | 484x420x44 mm | |||
| Weight | 9.8kg | 9.2kg | 8.8kg | 8.3kg |
| DSP (4 IN 4 OUT)Specifications | ||||
| Input PEQ | 31 PEQS | |||
| Output PEQ | 10 PEQS | |||
| Crossover | Butterworth, Bessel, Linkwitz6~24 | |||
| Output Delay | Input Delay: 2 x 80ms / Output Delay: 4 x 20ms | |||
| Output Compressor | Knee, Threshold, Attack, Ratio, Release | |||
| Output Limiter | Threshold-90dBu~21dBu, release 1~2895ms | |||
| DSP Presets | 30 (one for factory preset) | |||
| Control port | USB | |||
| DSP Channel | 4 Inputs & 4 Outputs | |||
